| Features | Authentication, valuation, sorting by denomination, orientation, facing through a complete analysis of the banknote using different sensors(optical,IR,UV and MG) | √ | ||
| Analysis of the JR pattern through a high resolution CIS. Authentication of the notes. | √ 2CIS | |||
| Fitness quality sorting(FIT/UNFIT) through a very stable analysis of the banknote state using different sensors and mechanisms(CIS-contact Image Sensor of 200dpi, powerful UV, mechanical thickness checking) | √ | |||
| Analysis by reflection on both side of the banknote and by transmission(resolution of 200dpi)made in visible and IR that allows a total stability in the fitness sorting of the banknotes | √ | |||
| Analisis of strong magnetic pattern and weak magnetic pattern of banknote and metal thread | ||||
| Capable to capture note serial NO. can be printed and stored in memory card. | ||||
| Checking of the washed banknotes. | √ | |||
| The most precise analysis of the quality of the banknotes(tear, adbesive,tape,double detection.) | √ | |||
| Very explicit drawings,completely configurable menu for the user,sub-meanus and rapid functions | √ | |||
| Currency type：USD, EUR, GBP, CNY, JPY, KRW, RUB, INR, IDR, TWD, HKD，etc. | √ | |||
| Communications | LAN /RS232/ USB/ PC | |||
| Storage | USB | |||
| Printer | Optional：Built-in printer | |||
| Specifications | Tactile screen | 4.3 Touch TFT | ||
| Process speed | 800/1000/1200 speed/min | |||
| Dimensions(mm) | 260*280 *275 | |||
| Net Weight (kg) | 9 | |||
| Carton Packing Details | Dimensions (mm) | 420*360*425 | ||
| Gross Weight (kg) | 12 | |||
| Quantity(pcs ) | 1 | |||
