PH-520 2025 New Design POS Scanner Handheld Android 11 Touch Screen Cash Payment Equipment NFC USB High-speed Thermal Printer

Android 11 Touch Screen Cash Payment Equipment NFC USB High-speed Thermal Printer
Description Details Video Download
· High-Speed Thermal Printer: Supports 58mm paper width, ideal for receipts and labels.
· NFC Support: Yes, for contactless payments (EMV standards).
· 1D/2D Barcode Scanner: Optional, supports various barcode systems.
· Dual SIM Support: Standard SIM card slot. 5.0" HD Display: IPS, 720x1280 resolution, 2-point multi-touch.
· Dual Cameras: 5MP rear (barcode scanning) and 2MP front.
· 4G LTE Connectivity: Supports multiple bands for global compatibility.
· Android 11 OS: ARM Cortex-A53 1.5GHz, 2GB/16GB  (expandable to 3GB/32GB or 3GB/64GB).
· Removable Battery: 7.4V/2500mAh, UN38.3 compliant.
· Compact Design: 183.6mmx80mmx57.6mm, 250g with battery.
 Features  Voice call  √
 Data  √
 SMS&MMS  √
 GPS  √
 Speaker  √
 Microphone  √
 Type-C charging/data cable
 MSR  ×
 ICCR  ×
 Customized power on/off screen  ×
 Specifications  system  Android 11
 CPU model  ARM Contex-A53 1.5GHz
 CPU Clock Range  1.5GHz
 RAM  2GB (3GB optional)
 EMMC  16GB (32GB/64GB optional)
 LCD Screen / Secondary screen  5.0" HD IPS
 Display Resolution  720*1280
 Fingerprint collection module(optional)  ×
 Communication  ×
 USB  1 x USB Type-C port, OTG supported
 Rear Camera / Front Camera  Front 2M FF Rear 5M FF + fill light
 Card Slot  1 SIM card (double-layer - top)
 Physical button  Power key×1, custom physical shortcut×2
 Backlit  /
 Touch Screen  2 point
 Printer  High-speed thermal printer, paper roll width 58mm, diameter 40mm 2-inch high-pressure, high-speed thermal printer Support label printing and black mark printing,barcode proofing and picture proofing
 NFC card  Optional Support 13.56MHZ,IISO / IEC 14443,ISO15693 A&B,Mifare,felica card Support card reading, card simulation, point-to-point
 SIM card bands  Default Europe & Asia version: FDD-LTE:B1/B3/B5/B7/B8/B20/B26/B28 TDD-LTE:B38/B39/B40/B41 WCDMA:B1/B2/B5/B8 GSM/EDGE/GPRS:850/900/1800/1900
 WIFI Module  Dual-band (2.4GHz/5GHz) single stream, 802.11 a/b/g/n
 Bluetooth  2.1+EDR/3.0+HS compliance/v4.2Low Energy (LE)
 Temperature Storage temperature: -20℃-70℃ Working Temperature: 0℃-50℃
 Power adapter  5V DC/2A
 Battery type  Lithium battery
 Battery capacity  2500mAh/7.4v,18650*2
 Certificate  ×
 Dimensions (mm)  183.6*80*57.6mm
 Net Weight (kg)  0.364
 Carton Packing Details  color box (cm)  19.8*9.8*8.8cm
 Color box weight (kg)  0.7326
 Box size (cm)  48.8*47.8*19.7cm
 Gross Weight (kg)  14.4
 Quantity(pcs)  20
