| Process of the banknotes • Basic functions : With three output pockets, banknotes are sorted automatically through a 3-way sort at a single pass, i.e. it values, verifies and classifies the banknotes simultaneously . • Advanced functions : F I T N E S S quality sorting(FIT/UNFIT)through a very stable analysis of the banknote satate using different sensors and CIS(Contact Image Sensor )of 200 dpi, powerful UV, full width mechanical thickness checking. Benefits of advanced technology • Optical/Visible Array : Analysis by reflection on both side of the banknote and by transmission (resolution of 200 dpi) made in visible and IR that allows a total stability in the fitness sorting of the banknotes . • IR sensor: Analysis of the IR pattern through a high resolution CIS. Authentication of the notes. • Magnetic sensor : Analysis of strong magnetic pattern (MG) and weak magnetic pattern (MG) of banknote and metal thread detection. • Sr.No.Capture : Capable to capture note serial no. can be printed and stored in memory card. • RGB and UV sensors: Checking of the washed banknotes . • Mechanical system of thickness checking: The most precise analysis of the quality of the banknotes (tear, adhesive, tape, detection of doubles). User Interface • Tactile screen: Large size colour touch screen with a resolution of 640×240 pixels. • User’ s information : Very explicit drawings, completely configurable menu for the user, sub-menus and rapid functions. • Communications: RS232 (printer, connection to a computer) Protocol PC, USB2.0, Ethemet/Lan/s. • Storage: SD card Process speed : 1000 / 800 ban k notes. NPM)/mi n: Authenticating, valuing, denomination and fitness quality sorting Capacity feeder: Up to 1000 banknotes Number of Stackers: 3output pocket+ 1 reject Capacity of the stackers: 3×100 banknotes extendable up to 200 banknotes by software. Reject pocket up to 100 Notes Capacity feeder: 650×420×450(HDL)mm Weight: 58kgsCurrency Currency type : USD, EUR, GBP, CNY, J P Y ( J a p a n ) , K R W ( K O R E A ) , UB(RUSSIA}, INR(India},IDR(Indonesia)） TWD(Taiwan)etc. |
| Features | Basic functions | With three output pockets, banknotes are sorted automatically through a 3-way sort at a single pass, i.e. it values, verifies and classifies the banknotes simultaneously . | ||
| Advanced functions | F I T N E S S quality sorting(FIT/UNFIT)through a very stable analysis of the banknote satate using different sensors and CIS(Contact Image Sensor )of 200 dpi, powerful UV, full width mechanical thickness checking. Benefits of advanced technology | |||
| Optical/Visible Array | Analysis by reflection on both side of the banknote and by transmission (resolution of 200 dpi) made in visible and IR that allows a total stability in the fitness sorting of the banknotes . | |||
| IR sensor | Analysis of the IR pattern through a high resolution CIS. Authentication of the notes. • Magnetic sensor : Analysis of strong magnetic pattern (MG) and weak magnetic pattern (MG) of banknote and metal thread detection. |
|||
| Magnetic sensor | Analysis of strong magnetic pattern and weak magnetic pattern of banknote and metal thread. | |||
| SN Capture | Capable to capture note serial no. can be printed and stored in memory card. | |||
| RGB and UV sensors | Checking of the washed banknotes. Mechanical system of thickness checking: The most precise analysis of the quality of the banknotes (tear,adhesive,tape,doublc detection.) |
|||
| Tactile screen | Large size colour touch screen with a resolution of 640x240 pixels. | |||
| User's information | Very explicit drawings, completely configurable menu for the user, sub-menus and rapid functions. | |||
| Communications | RS232 (printer, connection to a computer) Protocol PC, USB2.0, Ethemet/Lan/s. | |||
| Storage | SD card | |||
| Specifications | Process speed | 800/1000 banknotes/min: Authenticating, valuing, denomination and fitness quality sorting. | ||
| Number of Slackers | 3output pocket+ 1 reject Capacity of the stackers: 3×100 banknotes extendable up to 200 banknotes by software. | |||
| Capacity feeder | Up to 1000 banknotes | |||
| Size | 650x420x450mm | |||
| Weight | 42 kgs | |||
| Currency type | USD, EUR, GBP, CNY, JPY, KRW, RUB, INR, IDR, TWD, HKD etc. | |||
| Carton Packing Details | Dimensions (mm) | 650x420x450mm | ||
| Volume (m³) | 0.12 | |||
| Gross Weight (kg) | 58kg | |||
| Net Weight (kg) | 24.5kg | |||
| Quantity(pcs ) | 1 | |||
