| Features | High-speed decoding, responsive | √ |
| Strong versatility: USB, USB-COM and other interfaces are provided | √ | |
| Equipped with vibration feedback prompts | √ | |
| Compact, lightweight, ergonomically designed and comfortable in the hand | √ | |
| Support remote online upgrade | × | |
| Outstanding durability: IP54 rated for dust and water resistance, while withstanding a 1.5- meter drop to a concrete floor | √ | |
| Base | × | |
| Wireless design | × | |
| Specifications | Scan mode | Key trigger/auto-sensing/continuous scanning |
| Communication interface | USB-HID keyboard/USB-COM virtual serial port/RS232 serial port (optional) | |
| Wireless communication distance | ||
| Interface type | USB TYPE-B | |
| Prompt way | Buzzer, LED light | |
| How it's set up | Manually scan the setup codes one after the other | |
| Housing material | ABS+PC | |
| Cable standards | Straight line 1.6m | |
| Internal storage | ||
| Sensors | 300,000 roller shutters CMOS | |
| Resolution | 640*480 | |
| Light source | White LED | |
| Scan angle | ± 60°, ±60°, 360° (elevation, declination, rotation) | |
| Scan rate | 120 frames/sec | |
| Field of view | 48° (H) x 30° (V) | |
| Print contrast | 15% minimum | |
| Decode the kind | 1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, GS1 Composite 2D: QR Code, Data Matrix (DM), PDF417, MaxiCode, Aztec Code, support mobile screen reading | |
| Minimum resolution | 1D code 3.5mil; QR code 10MIL | |
| Depth of field | QR (15mil) 30~210mm QR payment code (mobile code) 80~550mm Data Matrix (10mil) 30- 140mm PDF 417 (6.7mil) 50- 120mm EAN-13 (13mil) 50~280mm Code 39 (8mil) 30- 190mm Code 128 (15mil) 80~320mm | |
| Input voltage | DC 5V±10% | |
| Current | Working: 350 mAh; Standby: 130 mAh | |
| Battery | ||
| Charging time | ||
| Battery life | ||
| Temperature | 0°C~50°C(working); -40°C~+60°C (storage). L46 | |
| Humidity | 5%-95% non-condensing | |
| Ambient brightness | Max.5,000 Lux (fluorescent) | |
| Seismic resistance | It can withstand a 1.5m drop in the air | |
| Dimensions (mm) | 160mm×66mm×95mm | |
| Weight (g) | 176 g | |
| Carton Packing Details | Dimensions (mm) | 1 95mm×105 mm×80mm |
| Gross Weight (kg) | 256.5g | |
| Quantity(pcs) | 1 |
